Trident A Plus 9th
Trident A Plus 9SD-609CA
|
|
| Operating Systems |
Windows 10 Home FREE Upgrade to Windows 11* 1Upgrade timing may vary by device. Features and app availability may vary by region. Certain features require specific hardware (see aka.ms/windows11-spec). |
|---|---|
| CPU Number | Intel Core i7-9700F |
| CPU Clock | 3.0GHz |
| CPU Cores | 8 |
| TDP | 65W |
| Cache | 12 MB SmartCache |
| Threads | 8 |
| Max Turbo Frequency | up to 4.70 GHz |
| CPU Cooler | Air cooling |
| Chipsets | B360 |
| Graphics | 8G, HDMIx1, Display Portx3, NVIDIA, GeForce RTX 2070 SUPER |
| Memory |
Memory Size 16GB(16GB*1) Memory Type DDR4 SDRAM Module Type U-DIMM Memory Slot(Total) 2 Memory Slot(Free) 1 Max Capacity Max 64GB |
| SSD Interface | PCIe GEN3x4 NVMe |
| Storage |
SSD Form Factor M.2-2280 M-KEY(1TB*1) SSD Size 1TB M.2 slots(Total) 2 M.2 slots(Free) 1 2.5" Drive Bays(Total) 2 2.5" Drive Bays (Free) 2 3.5" Drive Bays(Free) 0 |
| Audio | Realtek ALC892, 7.1 Channel HD Audio |
| LAN | Realtek RTL8111H |
| WLAN Version | 802.11ac 1x1+BT |
| BT Version | 5 |
| WLAN | INTEL/9462.NGWG.NV |
| USB 2.0 Type A | 1 |
| I/O Ports (Front) |
1 x USB 3.2 Gen 1 Type A 1 x USB 3.2 Gen 1 Type C |
| Audio Mic-in | 1 |
| Audio Headphone-out | 1 |
| I/O Ports (Rear) |
2 x USB 3.2 Gen 2 Type A (R) 2 x USB 3.2 Gen 1 Type A (R) |
| USB 2.0 Type A (R) |
2 4 |
| RJ45 | 1 |
| VGA out |
NA 1 |
| HDMI out |
NA 1x (v1.4) |
| DP out | 1x (v1.2) |
| PS/2 | 1 |
| DVI-D out | 1 |
| Audio jack | 6 |
| Power | 450W, 80PLUS BRONZE, SFX, POWER SUPPLY |
| Product Dimension (WxDxH) (mm) | 383 x 130 x 396 |
| Product Dimension (WxDxH) (inch) | 15.08 x 5.12 x 15.59 |
| Inside Carton Dimension (WxDxH) (mm) | 532 x 230 x 501 |
| Inside Carton Dimension (WxDxH) (inch) | 20.94 x 9.06 x 19.72 |
| Weight (Net kg) | 6.55 |
| Net Weight (lbs) | 14.44 |
| Weight (Gross kg) | 9.5 |
| Gross Weight (lbs) | 20.94 |
| Liter | 10.36 |
| Pint | 21.89 |
| Operating, Storage Temperature | 0° C ~ 35° C ; -20° C ~ 60° C |
| Operating, Storage Humidity | 0% ~ 85%;0% ~ 90% |
| Regulatory Compliance |
FCC(Class B) CB/CE UL(CUL) BSMI VCCI RCM(C-Tick) |
| Warranty | 12months |
| Power Cord | 1 |
| Warranty Card | 1 |
| Quick Guide | 2 |
| Keyboard | DS4200_K_US |
| Mouse | Clutch GM10 |
| UPC | 824142195048 |
| Part No | 9S6-B92641-609 |
| UCC14 | 10824142195045 |
| MKT Name | Trident A Plus 9SD |
| MKT Spec | Trident A Plus 9SD-609CA |
| Color | ID1/Black-Black-Black |
| Model | B926 |
